The Use of Oxygen in Plasma Cleaning Equipment



Oxygen gas, known for heightened reactivity and capacity to generate reactive oxygen species, assumes a pivotal role in oxygen plasma cleaning. The ensuing sections will delve into the intricacies of this application, elucidating how oxygen contributes to the removal of organic and organic substances.


This article delves into the application of oxygen in plasma cleaning equipment, highlighting its role in various industries and detailing its mechanisms in achieving effective surface treatment.


What Is Plasma Cleaning?

Plasma cleaning is a surface treatment process used in industries like semiconductor manufacturing, electronics, optics, and materials science. It involves using high-energy ionized gas, or plasma, to clean and alter the surface properties of materials.


The process begins by introducing a gas into a low-pressure chamber and energizing it using radiofrequency or microwave energy. This creates a plasma containing ions, electrons, and neutral particles.


The choice of process gas determines the plasma chemistry, which is tailored for specific cleaning or modification effects. The reactive species in the plasma react with contaminants and undesired materials on the substrate's surface, leading to their removal through chemical reactions and physical sputtering.


Plasma cleaning is adept at removing challenging residues like organic compounds and thin films. Furthermore, it allows for precise control of parameters such as gas composition, pressure, power, and exposure time. This level of control ensures desired outcomes without harming the substrate. Plasma cleaning is performed in a vacuum environment to facilitate plasma generation and prevent re-deposition of cleaned materials. Overall, it's a versatile and efficient method for achieving cleanliness and controlled surface modifications.


Understanding Oxygen Plasma



Oxygen is commonly used in plasma cleaning processes due to its high reactivity and ability to form reactive oxygen species (ROS) in the plasma. These ROS, such as oxygen ions and radicals, play a key role in breaking down and removing organic and carbonaceous contaminants from the surface of materials. Oxygen plasma cleaning is particularly effective for organic residue removal, surface activation, and oxidation processes.


Here's how oxygen is used in plasma cleaning:

  1. Gas Selection: Oxygen gas (O2) is introduced into a low-pressure chamber or reactor where the plasma cleaning process takes place. The choice of oxygen is based on its ability to readily ionize and form reactive species when subjected to plasma excitation.

  2. Plasma Generation: The oxygen gas is energized using radiofrequency (RF) or microwave energy, which ionizes the gas and forms a plasma. This plasma contains a mixture of oxygen ions (O+) and oxygen radicals (O and O-), along with electrons and neutral oxygen molecules.

  3. Contaminant Removal: Once the plasma is generated, the highly reactive oxygen species in the plasma interact with the contaminants present on the surface of the substrate. The oxygen radicals and ions chemically react with the organic and carbonaceous materials, breaking them down into volatile compounds that are easily removed from the surface.

  4. Physical Sputtering: In addition to chemical reactions, oxygen ions can physically sputter or dislodge contaminants from the substrate's surface. This process involves the momentum transfer of energetic ions to the surface, effectively knocking off the contaminants.

  5. Oxidation and Surface Modification: Oxygen plasma can also induce oxidation on certain materials, leading to changes in the material's surface chemistry. This can be advantageous for creating specific surface functionalities or improving wettability and adhesion properties.

  6. Activation of Surfaces: Oxygen plasma treatment can activate surfaces by introducing oxygen functional groups, which can enhance bonding with subsequently applied coatings, adhesives, or other materials.

It's important to note that while oxygen plasma is highly effective for cleaning and surface modification, it can also be aggressive and may lead to etching or damage of some materials if not properly controlled.


Careful adjustment of process parameters, such as plasma power, exposure time, and pressure, is necessary to achieve the desired cleaning or modification effects without causing unintended damage.


Plasma Ashing with Oxygen

Plasma ashing with oxygen is a specialized process used in semiconductor manufacturing to remove organic materials like photoresists or polymers from the surface of semiconductor wafers or substrates.


The process involves placing the substrate in a vacuum chamber and introducing oxygen gas, which is then ionized to create a highly reactive plasma containing oxygen ions and radicals. This plasma chemically reacts with the organic material, breaking down carbon-carbon bonds and forming volatile compounds that are removed from the chamber.


By carefully adjusting parameters such as plasma power, pressure, and exposure time, the organic material can be completely removed without damaging the substrate. This process is critical for preparing wafers for subsequent manufacturing steps, ensuring clean surfaces and accurate pattern transfer during photolithography and other processes.


What Industries Use Oxygen in Plasma Cleaning?

Oxygen plasma cleaning is utilized in various industries for its effectiveness in surface cleaning, etching, and modification. Some of the key industries that employ oxygen plasma cleaning, along with specific applications, include:

  1. Semiconductor Manufacturing: Oxygen plasma cleaning is extensively used in semiconductor fabrication processes. It is crucial for removing photoresist and other organic contaminants after lithography steps. This prepares the wafers for subsequent processing stages like deposition, etching, and ion implantation.

  2. Electronics: In electronics assembly, oxygen plasma cleaning is employed to remove organic residues and ensure proper adhesion of coatings, adhesives, and solder masks. It can be used to clean printed circuit boards (PCBs), wire bonding surfaces, and other electronic components.

  3. Optics and Photonics: Oxygen plasma cleaning is valuable in optics and photonics for cleaning delicate optical components, such as lenses, mirrors, and prisms. It helps maintain optimal performance by removing dust, oils, and other contaminants that can degrade optical properties.

  4. Medical Devices: In the medical device industry, oxygen plasma cleaning is used to prepare surfaces for bonding, coating, or other processes. It can help improve biocompatibility, remove contaminants from medical implants, and ensure proper adhesion of coatings for drug delivery systems.

  5. Aerospace and Aviation: Oxygen plasma cleaning is utilized to clean and prepare surfaces of aerospace components before bonding, coating, or painting. It aids in ensuring strong adhesive bonds and corrosion resistance in challenging environments.

  6. Materials Science and Research: Researchers use oxygen plasma cleaning to modify and clean surfaces of materials for experimental purposes. It helps create controlled surface chemistries and wettability properties for studies related to adhesion, thin films, and surface interactions.

  7. Nanotechnology: In nanofabrication, oxygen plasma cleaning is employed to clean and activate surfaces before the deposition or patterning of nanoscale materials. It assists in achieving precise and controlled nanopatterning.

  8. Biotechnology: Oxygen plasma cleaning can be used to sterilize and clean surfaces in biotechnology labs, particularly in microfluidics, cell culture, and biochip applications.

  9. Textiles: Oxygen plasma cleaning can be applied in the textile industry to modify the surface properties of fabrics, improving wettability or enhancing dye absorption.

  10. Automotive: In automotive manufacturing, oxygen plasma cleaning can be used for surface preparation before painting or bonding components, ensuring strong and durable finishes.


Final Thoughts

To sum up, plasma cleaning is an incredibly efficient method for treating surfaces, renowned for its exceptional ability to ensure cleanliness and eliminate contaminants. With continuous progress and enhancements in plasma cleaning technology, industries can confidently rely on this approach to fulfill the stringent standards for cleanliness demanded across a spectrum of applications, spanning from microelectronics to aerospace.


Distinguished by its reputable standing, SCI Plasma has a team of adept specialists who excel in delivering top-tier plasma cleaning solutions. Drawing upon their extensive expertise and experience, they prove to be invaluable partners for individuals and entities seeking guidance in the realm of plasma cleaning.


Whether you require an explanation regarding the intricacies of the plasma cleaning process, assistance in selecting the optimal equipment, or tailored solutions to suit your unique cleaning requisites, the proficient professionals at SCI Plasma are resolute in their dedication to aid you. Give us a call and let’s discuss how we can solve your plasma cleaning needs.
